首頁 » 產品中心 » 預過濾系列 » 自動卷繞式空氣過濾器

預過濾系列

自動卷繞式空氣過濾器



性能特點 Features


自動更換濾料
壓差控制
結構簡單
外框:AutoRoll 整體采用金屬結構,堅固可靠,可以滿足惡劣的工作環境。智能型濾料更換系統,可滿足復雜的氣流系統要求,有限的節約能源,降低人力,使運行更經濟穩定。
效率:(EN779:2002)G4,F5;
            (ASHRAE 52.2:2007)MERV7,MERV8。
濾料:由高性能抗斷的合成纖維過濾材料組成,遞增結構,容塵量大,效率高,不含硅


Automatic Renewable media Air Filter
Pressure Differential Detector System
Easy Installation,Simply Design

Autoroll-Filter constructed by cold roll steel with powder coated surface to provide a rigidly and reliable structure,which can withst and severe operating condition.This system is installed at environment require air filtration system ,frequent change of filter and accessibility is critical .Low power consumption,reduce manpower and reliable operation .
Efficiency:(EN779:2002 filter class)G4,F(xiàn)5
                    (ASHRAE 52.2:2007 filter class)MERV7,MERV8
Media:  the filter mats are Made of high performance polyester fibers with durable thermal bonding Increment structure, large dust capacity,Not silicon

結構說明 Design Descriptions


壓差辨別:通過壓差系統辨別過濾面是否需要更換,避免人為操作失誤造成的濾料及資源的浪費,確保過濾器在運行時達到佳的過濾效率及經濟的運營模式;
時間/壓差雙重控制:避免過多的將干凈濾料卷起,造成浪費;
濾料報警指示:當一卷濾料卷臨近用完,通過指示燈提示更換新濾料卷;
靈活的模塊拼裝:該裝置既可單******立使用,也可以多個單元拼接使用,滿足通風面積大的場所;
Automatic Renewable Media Controlled System
This is the corn design of Autoroll-Filter.The pressurize detector system controlled the renewable media without any human decision judgments.Thus ,minimize human error decision on renewable media and power consumption to ensure the finest efficiency rate and economic operation during services.

工作原理 Working principle
自動卷繞式過濾器上濾料箱裝上一卷新濾料,當大風量高濃度含塵空氣經外力引入,通過卷繞式過濾時,過濾器初阻力隨濾塵增加而逐步上升,當過濾器阻力上升至設計終值時,壓差開關動作,其開關信號輸入控制程序,自動啟動電機,電機運轉帶動下濾料卷軸轉動,從而將臟的濾料卷起來,同時過濾面上更換成干凈的濾料。直至整卷濾料用完時,通過手柄位置的改變將上濾料箱內的限位開關斷開,濾料報警指示燈(紅燈)亮,以示需更換新一卷濾料。
The controlled system has a pre-set value for final resistance .When the pressure value is equivalent or larger than preset value,the logo control will auto-matically roll the renewable media.The dirty media go downward and a clean media will take over.

應用Applications


工業通風、空調通風系統的第一級預過濾段
含塵量高,需頻繁更換濾料的工作環境
The primary filter of industrial-grade ventilation systems
High dust content,Need frequent replacement filter places

性能特點Features


材質表 Material Table

框架

Frame

冷軋板表機噴涂處理

Cold roll   steel ,powder coated surface

上濾料箱

Top Media

密封結構,確保干凈的濾料不會被污染

Seal tightly   to ensure the media will not be    contaminated

下濾料卷軸

Bottom Media   Support

卷繞過濾面上臟的濾料

To ensure   the dirty media will be rolled back properly after used

電控柜

Control  box

Logo/pcb控制裝置及控制電路

Pressure   differential switch

馬達傳動裝置

Motor

適用電壓Voltage50Hz: 110V,115V,200V,220V,230V)

               (60Hz:110V,220V,240V)

功率Power   200W(1/4HP)



濾料

Media

合成纖維,厚度10mm,15M/

Polyester   media in roll form

使用環境溫度

Operating   Temperature

-10?C~+40?C(Continuosly  operate)

過濾器總寬度Nominal Width                額定風量(m3/h)Rated Air Flow(m3/h)

英尺(毫米)ff(mm)                       過濾器總高度英寸(毫米)Norminal Height ff(mm)


5(1524)

6(1829)

7(2134)

8(2438)

9(2743)

10(3048)

11(3353)

12(3658)

13(3962)

14(3962)

15(4572)

03914

6413

8702

10991

13280

15569

17858

20147

22436

24725

207014

29303

041219

8756

11881

15006

18131

21256

24381

27506

30631

33756

36881

40007

051524

11099

15060

19021

22982

26943

30905

34866

38827

42788

46749

50711

061829

13441

18239

23036

27833

32631

37428

42225

47022

51820

56617

61415

072134

15784

21417

27051

32684

38318

43951

49585

55218

60852

66485

72119

082438

18127

24596

31066

37535

44005

50475

56944

63414

69883

76353

82823

092743

20469

27775

25081

42386

49692

56998

64304

71609

78915

86221

93527

103048

22812

30954

39096

47238

55379

63521

71663

79805

87947

96088

104231

113353

25155

34133

43111

52089

61067

70045

79022

88000

96978

105965

114935

123658

27497

37312

47126

56940

66754

76568

86382

96196

106010

115824

12539

133962

29840

40490

51141

61791

72441

83091

93741

104392

115042

125692

136343

144267

32183

43669

55156

66642

78128

89615

101101

112587

124073

135560

147047

154572

34526

46848

59170

71493

83815

96138

108460

120783

133105

145428

157751



164877

36868

50027

63185

76344

89503

102661

115820

128978

142137

155295

168454

175182

39211

53206

67200

81195

95190

109184

123179

137174

151169

165163

179158

185486

41554

56384

71215

86046

100877

115708

130594

145369

160200

175031

189862

195791

43896

59563

75230

90897

106564

122231

137898

153565

169232

184899

200566

206090

46239

62742

79245

95748

112251

128754

145258

161760

178264

194746

211270

216401

48582

95921

83260

100599

117939

135278

152617

169956

187295

204635

221974

226706

50924

69100

87275

105450

123626

141801

159976

178152

196327

214503

232678

237010

53267

72279

91290

110302

129313

148324

167336

186348

205359

224370

243382

247315

55610

75457

95305

115353

135000

154848

174695

194543

214391

234238

254086


1、若遇規格、結構變更,以本公司提供的新數據為準
2、本公司接受非標準規格的訂貨

1. If you meet specifications, structural changes, the company provides the newest data shall prevail
2.We accept the orders of non-standard specifications
